CNC 210
Rotary diameter | 210mm |
Machine body length | 400mm |
Machine body width | 100mm |
Spindle speed | 50-2500r/min |
Main cone taper | MT3 |
Z-axis movement speed | 2000mm/min |
X-axis movement speed | 1000mm/min |
Z-axis feed speed | 500mm/min |
X-axis feed speed | 250mm/min |
Z-axis maximum torque | 2Nm |
Maximum torque of X-axis | 2Nm |
Z-axis travel | 250mm |
X-axis stroke | X80mm |
Z-axis motor torque | 1.5N |
X-axis motor torque | 2N |
Number of tools | 4 |
Knife holder angle | 360° |
Tailstock taper | MT2 |
Tailstock stroke | 50mm |
Z/X-axis return accuracy | 0.01mm |
Tool rotation accuracy | 0.005mm |
Main motor power | 1200W |
Package size | 1530*660*1500mm |
Weight (n.w/g.w) | 300KG/250KG |
